The Truck Tire Valve Stem TR501 is designed for heavy-duty truck and bus tubeless wheels. Manufactured from premium brass with a high-quality EPDM rubber grommet, it provides excellent sealing performance under high tire pressures and demanding road conditions.
Designed for standard 0.625" (15.9 mm) valve holes, the TR501 offers reliable air retention, corrosion resistance, and long service life, making it an ideal replacement valve for commercial vehicle fleets, tire service centers, and wheel manufacturers. TR501 is commonly used on steel truck wheels with clamp-in installation and is typically rated for around 200 psi service.
Technical Product Data
Product Name
TR501 Truck Tire Valve Stem
Valve Type
Clamp-in
Material
Brass + Rubber + Steel Washer
Valve Hole
15.7 mm (0.625")
Effective Length
38 mm (1.5")
Maximum Pressure
200 PSI
Recommended Torque
4–6.2 N·m
Application
Tubeless Truck Tires
TR501 Clamp-in Brass Tire Valve Stem for Heavy Truck Trailer Tubeless Wheel
TR501 is standard brass clamp-in tubeless valve for heavy trucks and trailers. Made of corrosion-resistant nickel-plated H62 brass, it fits standard 15.9mm round rim holes, supports up to 14Bar working pressure. Complete with rubber grommet, washer, nut and metal dust cap. Each valve undergoes raw material inspection, machining test, high-pressure air tightness test and final packaging QC. Custom logo, upgraded FKM seals and personalized packaging are available for wholesale buyers.
Thick brass valve body, heavy-duty resistant to manufacturing
Double layer sealing to prevent slow air leakage
rustproof and corrosion-resistant
Dynamic balance and stability
Product Advantages
Reliable Air Seal
The premium EPDM rubber grommet creates a dependable airtight seal, reducing air leakage even under continuous high-pressure operation.
Heavy-Duty Brass Body
Solid brass construction provides excellent mechanical strength and corrosion resistance for long-term outdoor use.
High Pressure Performance
Suitable for commercial vehicle tires operating up to approximately 200 PSI.
Easy Replacement
Clamp-in installation allows quick replacement during tire servicing.
Long Service Life
Designed to withstand vibration, temperature changes, moisture, and harsh road environments.
OEM Options
Surface processing, tape selection, labeling and packaging can be customized according to customer requirements.
The TR501 valve stem is widely used for:
Heavy-duty trucksCity BusesCommercial TrailersCoachesAgricultural Cehicles Construction MachineryFleet MaintenanceTire Service WorkshopsFleet MaintenanceTire Service Workshops
Standard Box Packing with Custom Branding Support
LogoCustomized LOGO Carving
Laser engraving of customer trademarks and corporate logos on brass rods and dust caps.
Print customer logos and brand names. Printing brand labels, place of origin, specifications, and moisture-proof labels on cardboard boxes.
Clean, Press and Wait for Strong Adhesion
01Release the air and remove the old valve
Lift up the vehicle, release the tire pressure, remove the tire, and remove the old valve; Clean the rust and residue of the wheel rim installation holes and old sealing rings, and check for any deformation or burrs in the hole positions.
02Assemble a brand new tire valve and seal it
Lock evenly with standard torque to prevent deviation and slow air leakage; Adjust the valve angle to avoid friction with the tire wall, and install a brand new high-temperature resistant valve core.
03Testing+Dynamic Balance Loading
Inflate to the standard tire pressure of the vehicle and check for any air leaks; Perform tire dynamic balancing; Recheck the tire pressure during the loading road test to confirm that there is no leakage or shaking, and then complete the replacement.
Tip: Control the torque and avoid violent twisting. Excessive torque can cause fracturing of the rubber ring and deformation of the wheel rim hole; Insufficient torque leads to turbulence, looseness, and air leakage in the later stage.
Controlled Details from Weight Accuracy to Finished Packing
01Incoming Material Inspection
100% sampling inspection of all raw materials; The spectrometer detects the composition of brass material to eliminate the problems of cracking and corrosion caused by impurities in copper.
02Process Inspection
Micrometer measuring rod length, base diameter, thread; Full inspection of thread gauge to ensure smooth assembly without slipping threads.. Remove semi-finished products that are prone to rust.
03Airtightness Test
High pressure airtight water immersion test: Simulate the working pressure of a heavy truck at 14Bar to maintain pressure, and observe the entire process without any bubbles or leaks; Torque and voltage withstand test.
04Final Inspection
Full inspection of appearance scratches, coating peeling, and laser logo clarity; Control the weight tolerance of the entire machine to ensure stable dynamic balance.
Review Screenshots
Frequently Asked Questions
What vehicles use the TR501 valve stem?
TR501 is primarily used on heavy-duty trucks, buses, trailers, and other commercial vehicles equipped with tubeless steel wheels.
What rim hole size does TR501 fit?
It fits the standard 15.7 mm (0.625") valve hole used on many commercial truck wheels.
Is the TR501 suitable for high-pressure tires?
Yes. The TR501 is designed for commercial vehicle applications and supports tire pressures up to approximately 200 PSI, depending on the wheel and tire specifications.
Can you provide OEM service?
Yes. We offer OEM manufacturing, custom logos, customized packaging, barcode labels, and private branding.
